Eco Capture AIO M.2

Key Features:

Input:

• Supports multiple input interfaces including HDMI, SDI, DVI, VGA, and Component with resolutions up to 2048x1080 60fps
• Supports 3G-SDI, HD-SDI, SD-SDI formats via SDI input
• Embedded audio support for up to 8-channel, 48KHz, 16-bit audio

Processing:

• High-quality video processing including up/down/cross-scaling, deinterlacing, and color space conversion
• 10-bit video processing engine for accurate color reproduction

Output:

• M.2 interface for high-speed data transfer
• Ultra-low latency output suitable for real-time applications

Additional Features:

• Low power consumption, ideal for embedded systems
• Compatible with Windows, Linux, and Mac OS platforms
• Compact design suitable for small form factor installations
• Advanced configuration and status monitoring via software

Included Accessories:

• None (designed for integration into systems)
